FTP250 Friulair Replacement Filter

FTP250

$540.00


P Filtration Grade 3 µm (micron)

Filtration grade Air quality Application example
P SERIES - 3 MICRONS
green


Filter capable to separate emulsion and particles down to 3 micron. Normally installed on the inlet of dryers. Ideal as pre-filter for on-line filters (series S – X – Z), and for vacuum pumps, pneumatic blowing plants.
SERIE S SERIES - 1 MICRONS
red


Filter capable to separate particles down to 1 micron, liquid an oil included. Maximum contents of residual oil 0,1 mg/m3. Normally used on outlet of dryers as (X) grade pre-filter. Used to prevent the deterioration of the pipes of compressed air plants, for surface treatment, on vacuum pump exhaust, on compressed air motors, and as post-filter for adsorption dryers.
SERIES - 0.01 MICRONS
yellow


Oil removing filter capable to separate residual oil and extremely small particles down to 0,01 micron. Maximum contents of residual oil 0,01 mg/m3. It produces air technically free from oil. Used for the protection of control system, pneumatics haulage, painting system and as pre-filter for adsorption dryers.
SERIES - ACTIVATED CARBON
black


Activated carbon filter for the elimination of oil vapours and odour. When installed, after a (X) grade filter, it lowers the maximum contents of residual oil 0,003 mg/m3. Used in the pharmaceutical industry, for dental applications, in photographic workshops,  packaging and galvanic treatments.

(FP250)

SKU FP250
Brand Pilot / Friul Air
Shipping Weight 1.0000kg
Shipping Width 0.080m
Shipping Height 0.200m
Shipping Length 0.080m
