MSFW-240-50/60-OD Solenoid coil 240 V AC: 50/60 Hz, pick-up power 9.0 VA, holding power 7.0 VA

MSFW-240-50/60-OD

$72.38
RRP $81.10
SAVE $8.72 (11%)




Solenoid coil

MSFW-240-50/60-OD

34424

GTIN: 4052568067939

Downloads



VACS_EN.PDF

Technical data

Links

Spare parts

Solenoid coil

Technical Data

  • Mounting position optional
  • Switching position indicator no
  • Min. pick-up time10 ms
  • Duty cycle100%
  • Power factor (cos phi)0.7
  • Characteristic coil data 240 V AC: 50/60 Hz, pick-up power 9.0 VA, holding power 7.0 VA
  • Permissible frequency fluctuations +/- 5%
  • Permissible voltage fluctuations +/- 10 %
  • CE mark (see declaration of conformity) To EU Low Voltage Directive
  • CE marking (see declaration of conformity) To UK regulations for electrical equipment
  • LABS (PWIS) conformity VDMA24364-C1-L
  • Degree of protection IP65
  • Ambient temperature -5 °C ... 40 °C
  • Max. tightening torque for socket 0.4 Nm
  • Product weight 55 g
  • Electrical connection 3-pin Plug pins with connection pattern to Festo standard for MSSD-F
  • Type of mounting Via knurled nut
  • Note on materials RoHS-compliant
  • Material solenoid coil Duroplast Copper Steel
  • Material winding Copper

(34424)

SKU 34424
Brand FESTO
Shipping Weight 1.0000kg
Shipping Width 0.080m
Shipping Height 0.200m
Shipping Length 0.200m
